A sewage pump is an indispensable piece of equipment for any home where plumbing fixtures are located below the main sewer line. Unlike a sump pump that handles relatively clean groundwater, a sewage pump is designed to move wastewater containing soft solids from a basement bathroom, laundry room, or wet bar to the main sewer or septic line. Installing a sewage pump is a complex DIY project that requires mechanical skill, electrical knowledge, and a meticulous approach. This comprehensive guide will walk you through the entire process, from planning to final testing, ensuring a safe and effective installation.
Before you purchase a single tool, it's crucial to understand what you're working with. A typical sewage pump system consists of:
· The Pump Itself: A submersible unit with a impeller designed to handle solid waste.
· The Sewage Basin: A large, durable pit (sump basin) that collects the wastewater.
· Check Valve: Preents pumped wastewater from flowing back into the basin after the pump shuts off.
· Discharge Pipe: The PVC pipe that carries the waste to the main sewer line.
· Pump Switch: A float switch that automatically activates the pump when the water level rises to a certain point.
Key Planning Steps:
1.Check Local Codes: Always consult your local building codes and obtain any necessary permits. Regulations regarding sewage ejection can be strict for public health reasons.
2.Choose the Right Pump: Not all sewage pumps are created equal. You need to select one with adequate power for your application. Consider:
· Horsepower (HP): Ranges from 1/3 HP for a single bathroom to 1 HP or more for multiple fixtures or high vertical lifts.
· Head Pressure: The total vertical height the pump must push water, plus the friction from pipe runs. A higher head rating is needed for longer distances.
· Materials: Cast iron or stainless steel pumps offer greater durability than thermoplastic.
The table below provides a general guideline for pump selection based on common residential applications:
| Application | Recommended Horsepower (HP) | Typical Basin Diameter | Notes |
|---|---|---|---|
| Single Basement Bathroom | 1/2 HP | 18 inches | Suitable for a toilet, sink, and shower. |
| Laundry Room or Wet Bar | 1/3 HP | 16 inches | Handles sink and washing machine discharge. |
| Multiple Bathrooms or Full Apartment | 3/4 HP to 1 HP | 24 inches | Required for high-volume applications; check local codes. |
Tools and Materials You'll Need:Sewage pump kit, PVC discharge pipe & fittings, PVC primer & cement, check valve, hose clamp, gravel, shovel, hole saw, pipe wrench, electrical connectors, wire nuts, GFCI outlet (if not already installed).
Step 1: Prepare the Sewage Basin and Discharge LineExcavate the area where the basin will be placed. The hole should be wide enough to accommodate the basin with a few inches of clearance on all sides. Lay a 2-3 inch bed of gravel at the bottom for drainage and stability. Next, dig a trench for the discharge pipe from the basin to the main soil stack or sewer line, ensuring it has a slight downward slope (1/4 inch per foot) away from the basin to prevent backflow.
Step 2: Install the Discharge Fitting and PumpUsing a hole saw, create an opening in the basin for the discharge pipe. Install the discharge fitting, sealing it according to the manufacturer's instructions. Attach a length of PVC pipe to this fitting that will rise vertically inside the basin. Lower the sewage pump into the center of the basin, ensuring it sits level on the bottom.
Step 3: Plumb the Check Valve and Discharge PipeAttach the check valve to the pump's discharge outlet, ensuring the arrow on the valve points away from the pump (towards the main sewer line). The check valve is critical for preventing backflow, which can cause the pump to short-cycle and burn out. Then, connect a vertical section of PVC pipe from the check valve to the discharge fitting you installed in Step 2. Use a union fitting just above the check valve to allow for easier future service and removal of the pump.
Step 4: Wire the Pump and Float SwitchSafety First: Ensure the power is turned OFF at the circuit breaker. Run the pump's power cord and the float switch cord up and out of the basin. Follow the manufacturer's wiring diagram meticulously. Typically, you will connect the pump and float switch wires to a designated, GFCI-protected circuit. It is highly recommended to have a licensed electrician perform this step if you are not confident in your electrical skills.
Step 5: Seal the Basin and BackfillOnce all plumbing and wiring are in place, run the discharge pipe through the trench and connect it to the main sewer line using a proper wye fitting. Seal the lid of the sewage basin tightly to prevent odors and soil from entering. Carefully backfill around the basin with the excavated soil or gravel, tamping it down firmly as you go.
Your installation is not complete until you've tested the system thoroughly.
1.Final Testing: Restore power at the circuit breaker. Slowly pour several gallons of water into the basin. Watch the float switch rise until it triggers the pump. The pump should turn on, move the water up and out through the discharge pipe, and then shut off automatically once the water level drops. Listen for any unusual noises.
2.Inspect for Leaks: Check all pipe connections, both inside the basin and along the discharge line, for any signs of leakage.
3.Routine Maintenance: To ensure your sewage pump has a long service life, perform simple maintenance every few months. Check that the float switch moves freely and isn't obstructed by debris. Listen for unusual noises during operation. It's also a good practice to test the pump periodically by pouring water into the basin.
While a determined homeowner can install a sewage pump, know your limits. You should absolutely call a licensed plumber or electrician if:
· You are uncomfortable working with electricity.
· The installation involves breaking into the main home sewer line.
· You encounter unexpected problems like bedrock, high water tables, or complex code requirements.
· You are unsure about the correct sizing of the pump or components.
A professional installation guarantees compliance with codes, ensures system efficiency, and provides peace of mind, protecting your home from the significant damage a failed sewage pump can cause.
By following this guide, you can confidently approach the task of installing a sewage pump, adding valuable, functional space to your home while safeguarding its foundation and plumbing integrity.
