Choosing the right submersible pump is crucial for an effective and efficient irrigation system. A pump that's too small won't deliver enough water, leaving your crops or lawn thirsty. One that's too powerful can waste energy, increase your electricity bills, and potentially damage your system through excessive pressure.
So, how do you find the perfect balance? This guide will walk you through everything you need to know to select the right size submersible irrigation pump for your needs. We'll cover key concepts like flow rate and pressure, explain how to calculate your system's requirements, and provide practical examples to make the process clear and simple. By the end, you'll be able to confidently choose a pump that keeps your landscape green and your system running smoothly.
Before you can choose a pump, you need to understand two fundamental concepts: flow rate and pressure. These are the two primary factors that determine a pump's performance and suitability for your irrigation system.
Flow rate is the volume of water the pump can move over a specific period, usually measured in gallons per minute (GPM). Your system's required flow rate is determined by the total amount of water your sprinkler heads or emitters need to operate at the same time.
To find this, you need to know the GPM for each sprinkler head in a single irrigation zone. An irrigation system is typically divided into zones to ensure adequate pressure and water coverage. You only need to calculate the GPM for the zone that requires the most water.
You can find the GPM for each sprinkler head in the manufacturer's product specifications. Simply add up the GPM of all heads in your largest zone to get the total required flow rate.
Example:
Imagine your largest irrigation zone has 5 sprinkler heads, and each one has a flow rate of 2 GPM.
Calculation: 5 heads x 2 GPM/head = 10 GPM
Result: You need a pump that can provide at least 10 GPM.
1
Pressure is the force that pushes water through your pipes and out of the sprinkler heads. It's measured in pounds per square inch (PSI). Your sprinkler heads have an optimal operating pressure range, also listed in the manufacturer's specifications. If the pressure is too low, the water won't spray far enough, leading to poor coverage. If it's too high, it can create misting, cause uneven distribution, and damage the sprinkler heads.
Calculating the required pressure is more complex than calculating flow rate because you have to account for several sources of pressure loss, collectively known as Total Dynamic Head (TDH).
Total Dynamic Head (TDH) represents the total equivalent height that water must be lifted, considering all the friction and pressure losses in your system. It's the total pressure your pump needs to generate. You calculate it by adding up the following components:
Operating Pressure: The pressure required for your sprinkler heads to work correctly (in PSI).
Elevation Head: The vertical distance (in feet) from the water source to the highest point in your irrigation system.
Friction Loss: The pressure lost due to friction as water moves through pipes, valves, and fittings.
Let's break down how to find each value.
Check the manufacturer's specifications for your sprinkler heads. For example, a typical residential sprinkler head might require 30 PSI to operate effectively.
Measure the vertical distance from the water level of your well, pond, or tank to the highest sprinkler head in your yard. Every 2.31 feet of vertical elevation equals 1 PSI of pressure loss.
Formula: Elevation Head (in PSI) = Vertical Height (in feet) / 2.31
1
Friction loss is the trickiest part to calculate. It depends on the pipe's diameter, length, and the flow rate of the water moving through it. Longer, narrower pipes create more friction than shorter, wider ones.
The table below provides a simplified estimate of friction loss in PSI per 100 feet of PVC pipe for common sizes and flow rates.
Flow Rate (GPM) | 1" Pipe (PSI Loss) | 1.25" Pipe (PSI Loss) | 1.5" Pipe (PSI Loss) | 2" Pipe (PSI Loss) |
|---|---|---|---|---|
5 GPM | 1.0 | 0.3 | 0.2 | 0.0 |
10 GPM | 3.8 | 1.1 | 0.5 | 0.2 |
15 GPM | 8.1 | 2.3 | 1.1 | 0.4 |
20 GPM | 13.9 | 3.9 | 1.9 | 0.6 |
25 GPM | 21.0 | 6.0 | 2.9 | 0.9 |
To find your total friction loss, add about 10-20% to account for valves and fittings.
Formula: Total Friction Loss = (Pipe Length / 100) * PSI Loss from table + (15% for fittings)
Once you have these three values, you can calculate your total required pressure.
TDH (in PSI) = Operating Pressure + Elevation Head + Total Friction Loss
Example Calculation:
Let's build on our earlier example:
Required Flow Rate: 10 GPM
Operating Pressure: 30 PSI
Vertical Elevation: The highest sprinkler is 20 feet above the water source.
Elevation Head = 20 ft / 2.31 = 8.7 PSI
Pipe System: You are using 200 feet of 1.25-inch PVC pipe.
Friction loss for 10 GPM in a 1.25" pipe is 1.1 PSI per 100 feet.
Pipe Friction = (200 ft / 100) * 1.1 PSI = 2.2 PSI
Add 15% for fittings: 2.2 PSI * 0.15 = 0.33 PSI
Total Friction Loss = 2.2 + 0.33 = 2.53 PSI
Total Required Pressure (TDH):
TDH = 30 PSI + 8.7 PSI + 2.53 PSI = 41.23 PSI
So, you need a submersible irrigation pump that can deliver 10 GPM at approximately 42 PSI.
With your required flow rate (GPM) and pressure (PSI) calculated, you're ready to look at pump performance charts, also known as pump curves. Every pump model has a chart that shows its performance at various points.
The chart will have GPM on the horizontal axis (x-axis) and PSI (or Head in feet) on the vertical axis (y-axis). To find the right pump:
Locate your required flow rate (10 GPM in our example) on the bottom axis.
Move up that line until you intersect with your required pressure (42 PSI).
Choose a pump whose performance curve is on or above this point.
It's always a good idea to select a pump that slightly exceeds your requirements. This gives you a safety margin and ensures the pump isn't constantly working at its maximum capacity, which can extend its lifespan.
By accurately calculating your system's needs, you can select a submersible irrigation pump that operates efficiently and provides years of reliable service. Taking the time to do these calculations upfront will save you from the frustration and expense of an underperforming or oversized pump. If you're still unsure, don't hesitate to consult with an irrigation professional who can verify your calculations and help you make the right choice.
Horsepower is a measure of the motor's power, but it doesn't directly tell you the pump's performance (GPM and PSI). Two pumps with the same HP can have very different flow rates and pressure outputs. Always select a pump based on its GPM and PSI capabilities from the pump curve, not just its horsepower.
While a small safety margin is good, a significantly oversized pump is a bad idea. It will operate inefficiently, leading to higher energy costs. The excessive pressure can also cause misting at the sprinkler heads, leading to water waste, and can stress or damage pipes and fittings over time. This is known as "dead-heading" and can shorten the pump's life.
The well recovery rate is the speed at which water refills your well after being pumped out. It's crucial that your pump's flow rate (GPM) does not exceed your well's recovery rate. If it does, you could run your well dry and damage the pump. If your well has a low recovery rate, you may need a system with a storage tank or choose a pump with a lower GPM.
A submersible pump is placed directly in the water source (like a well or cistern) and pushes water up to the surface. They are generally more efficient and quieter. A jet pump is located on the surface and pulls water up through suction. Jet pumps are typically used for shallow water sources (less than 25 feet deep), while submersible pumps are necessary for deeper wells.
