There is nothing quite as frustrating as a water system that stops working unexpectedly. When you rely on a well for your home, farm, or industrial facility, a malfunction can bring everything to a grinding halt. Often, the culprit is the heart of the system: the submersible pump motor. But how do you know if the motor is truly broken, or if the issue lies elsewhere, like in the wiring or control box?
Diagnosing a submersible water pump motor doesn't always require calling in a professional immediately. With a few basic tools—specifically a multimeter and an insulation resistance tester (megohmmeter)—you can perform several diagnostic tests yourself. These tests can save you time and money by pinpointing whether the motor needs replacement or if a simple electrical fix will solve the problem.
This guide will walk you through the essential steps to test a single-phase and three-phase submersible motor. We will cover how to check for grounding issues, verify winding resistance, and interpret your findings to ensure your water supply is back up and running as quickly as possible.
Before you begin pulling up any pipes or opening control boxes, safety is paramount. Always ensure the power is completely disconnected at the breaker panel. Dealing with water and electricity requires extreme caution.
To perform a comprehensive test on a submersible pump motor, you will need the following tools:
Digital Multimeter: This is used to measure voltage and winding resistance (Ohms).
Megohmmeter (Megger): This specialized tool measures insulation resistance and is crucial for detecting ground faults (short circuits to the earth).
Safety Gear: Insulated gloves and safety glasses are recommended.
Manufacturer’s Data Sheet: Having the specific resistance values for your motor model (often found in the manual or on the manufacturer's website, like Ruirong Pump’s product pages) is incredibly helpful for comparison.
1
The first and arguably most critical test is checking the insulation resistance. This test determines if the insulation around the motor windings has broken down, causing electricity to leak to the ground (the motor casing or the earth). A motor with a ground fault can be dangerous and will likely trip the breaker repeatedly.
Set your megohmmeter to 500 volts DC. If you are testing an older system, ensure you aren't using a voltage setting that exceeds the motor's rating significantly, though 500V is standard for most submersible pumps.
Connect one lead of the megohmmeter to the ground wire (usually green) coming from the motor. Connect the other lead to one of the motor’s power wires (typically black, red, or yellow).
Activate the tester and read the resistance value. You will repeat this for all power wires relative to the ground.
Here is a general guide to interpreting your insulation resistance readings:
Resistance Reading (Ohms/Megohms) | Condition of Motor Insulation |
|---|---|
20,000,000+ Ohms (20 Megohms) | Excellent: Motor insulation is in new or like-new condition. |
10,000,000 - 20,000,000 Ohms | Good: Motor is in serviceable condition. |
2,000,000 - 10,000,000 Ohms | Fair: Insulation is degrading; monitor closely. |
500,000 - 2,000,000 Ohms | Poor: Motor may still run but is nearing failure. |
Less than 500,000 Ohms | Failed: Severe insulation breakdown. The motor must be pulled and replaced/repaired. |
Note: If you are testing the cable along with the motor (from the surface), a low reading could indicate a nick or break in the submerged cable rather than the motor itself. To be certain, you would need to lift the pump and test the motor directly at the splice.
Once you have confirmed the insulation isn't grounded, the next step is to check the health of the internal windings. This test checks for open circuits (broken wires) or short circuits (wires touching each other where they shouldn't).
This process differs slightly depending on whether you have a single-phase or three-phase submersible motor.
Single-phase motors typically have a Start winding and a Run winding. You will be measuring the resistance between the Common (Black), Start (Red), and Run (Yellow) wires.
Set your Multimeter: Turn the dial to the lowest Ohm (Ω) setting (usually 200).
Measure Main vs. Start: Measure resistance between Black (Common) and Yellow (Run). This is your main winding resistance.
Measure Start vs. Common: Measure resistance between Black (Common) and Red (Start). This is your start winding resistance.
Check the Total: Measure resistance between Red (Start) and Yellow (Run).
1
The Rule of Thumb: The resistance of Red-to-Yellow should roughly equal the sum of the Black-to-Yellow and Black-to-Red readings.
Measurement Pair | Expected Result | Interpretation of Failure |
|---|---|---|
Common to Run (Black-Yellow) | Lowest resistance reading | If infinite (OL), winding is broken (open). |
Common to Start (Black-Red) | Medium resistance reading | If zero, winding is shorted. |
Start to Run (Red-Yellow) | Highest reading (Sum of above) | If reading is far below sum, potential short. |
Three-phase motors are simpler because all three windings should be balanced.
Measure Pairs: Measure resistance between Line 1 and Line 2, Line 2 and Line 3, and Line 3 and Line 1.
Compare: All three readings should be nearly identical.
If one reading is significantly lower or higher than the others, you likely have a burnt winding or a break in the circuit, and the submersible pump motor will need to be replaced.
Sometimes, the motor passes the electrical "health check" (Ohms and Ground tests) but still fails to pump water. In this scenario, the issue might be mechanical or electrical supply-related rather than internal motor damage.
Use your voltmeter to check the voltage at the pump disconnect or pressure switch.
Is voltage present? If not, check breakers and fuses.
Is the voltage correct? A 230V motor running on 200V will overheat and fail. Ensure the supply matches the nameplate requirements.
1
If the motor runs but pumps little water, or trips the overload after a few minutes, checking the amperage is useful. You will need a clamp-on ammeter for this.
Turn the system on.
Clamp the ammeter around one of the power wires (black, red, or yellow).
Compare the reading to the "Max Amps" or "Service Factor Amps" (SFA) on the motor nameplate.
High Amps: Could indicate a locked rotor (pump is jammed with sand/debris), bad bearings, or low voltage.
Low Amps: Usually indicates the pump is running freely but not moving water, which suggests a broken shaft, stripped coupling, or the pump is air-locked (dry well).
1
Deciding when to repair versus replace can be tricky. However, if your testing reveals a ground fault (low megohm reading) or an open winding (infinite resistance on the multimeter), the motor is effectively dead. Submersible motors are hermetically sealed units; opening them for repair is rarely feasible for the average user and often voids warranties.
If your tests point to a failure, replacing the unit with a high-quality option is the best long-term solution. Ruirong Pump offers a wide range of reliable 50Hz and 60Hz submersible motors designed for longevity and harsh conditions. Whether you need a 4-inch encapsulated motor for a residential well or a robust 8-inch water-cooling motor for industrial use, ensuring you select a model with the right specifications is crucial to avoiding future headaches.
Yes, you can perform preliminary tests from the top of the well head. By disconnecting the wires at the control box or pressure switch, you can measure winding resistance and insulation resistance through the drop cable. However, if you find a fault, you won't know for certain if the break is in the motor or the cable until you pull the pump and test the motor directly.
The most common causes include voltage surges (lightning), running dry (no water in the well), rapid cycling (tank waterlogged), and overheating due to scale buildup or low voltage.
Proactive testing isn't usually necessary for residential systems unless you notice performance drops. However, for critical agricultural or industrial applications, an annual insulation resistance test (Megger test) can track insulation degradation before a catastrophic failure occurs.
